Concealed Steel Hinge - Model #103, The hinge is invisible when closed., Finish Satin Brass

Richelieu's concealed hinges offer superior appearance and durability with contemporary and functional style. They easily install and can be used for many applications on wood or metal doors to meet all your needs.

FinishSatin Brass
Typeof HingeWood or Metal
Minimum Door Thickness3/4 in
MaterialSteel
Hinge Opening Angle+180?
For Hinge #103
Wood Screw Sizes#6 x 1" (3.5 mm x 25 mm)
Dimension A1/2 in
Dimension B3/8 in
Dimension C1 1/2 in
Dimension D1/8 in
Dimension E1/8 in
Dimension F11/16 in
Dimension G1/32 in
Dimension H19/32 in
Dimension I7/32 in
Packaging formatPair
