Concealed Steel Hinge - Model #220, The hinge is invisible when closed., Finish Satin Brass

Richelieu's concealed hinges offer superior appearance and durability with contemporary and functional style. They easily install and can be used for many applications on wood or metal doors to meet all your needs.

Finish Satin Brass
Typeof HingeWood or Metal
Minimum Door Thickness2 in
MaterialSteel
Hinge Opening Angle+180?
For Hinge #220
Wood Screw Sizes#12 x 1-1/2" (5.5 mm x 38 mm)
Dimension A1 3/8 in
Dimension B1 1/16 in
Dimension C5 1/2 in
Dimension D1/2 in
Dimension E9/32 in
Dimension F2 15/16 in
Dimension G1/16 in
Dimension H1 63/64 in
Dimension I15/32 in
Packaging format Per unit
