PL 2550 BI-FOLDING Door System for Closets with 3/4 (19 mm) thick doors, No floor guides; doors travel from side to side.,

The Ducasse PL2550 bi-folding door system is ideal for wardrobes and traditional reach-in closets. This system is engineered to work with Euro-style concealed hinges and works without a bottom guide track.
Some technical features:
- Max. single panel width 19 5/8" (500 mm) or 393/8" (1000mm) 2 folding leaves
- Smooth-running ball bearing trolley
- No fascia required for the top mount aluminum upper track
- Simple 1 3/8" (35 mm) diameter door-prep for thin panels

Typeof DoorWood
Door ThicknessMin. 18 mm
Weight Capacity per DoorMax. 40 kg
Door PositionFull Overlay
Track MountingSurface - Inside the Cabinet
Design IntentWardrobe, Pantry, Cabinet, Storage
Door Mounting MethodDrill
Roller PositionUpper
Rail Material Anodized Aluminum
Rail Finish Satin Aluminum
Roller Type Premium Ball Bearing
Rail Length2 to 3 m
Drilling Depth13 mm
Door WidthMax. 1 000 mm
OpeningLeft and Right-Hand Opening
Usable with an Aluminum ProfileMinimum Frame Size: 43 mm
Drilling35 mm
OperationSingle Fold
Packaging format Box
